Technical Overview
Frameset
Frame:
Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance | ICS Technology Stealth Cable Routing | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance | Internal Cable Routing | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Stem:
BMC ICS2 | Integrated Cockpit System Technology
Handlebar:
BMC RAB 02 | Ergo Top Shape | Compact Bend
Seat
Seatpost:
Roadmachine 01 Premium Carbon D-Shaped Seatpost
Saddle:
Fizik Argo Tempo R5 | 150mm
Drivetrain
Crankset:
SRAM Force
Chainrings:
46-33T
Cassette:
SRAM Force XG-1270
Cassette Size:
10-36T
Chain:
SRAM Apex
Front Derailleur:
SRAM Force eTap AXS
Rear Derailleur:
SRAM Force eTap AXS
Shifters:
SRAM Force eTap AXS HRD
Gears:
2 x 12
Bottom Bracket:
PF86 Bottom Bracket
Brakes
Brake Levers / Calipers:
SRAM Force eTap AXS HRD
Rotors:
SRAM Centerline X
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
CRD-321 SL Carbon | Tubeless Ready | 35mm
Hubs (F/R):
CRD-321 SL
Tires:
Vittoria Corsa N.EXT | 28mm
Additional Information
Tire Clearance:
33mm measured tire
Weight without Pedals:
8.08 kg | Size 54
ASTM Classification:
Level 1
System Weight Limit:
110kg
