Technical Overview
Frameset
Frame:
Teamelite 02 - Big Wheel Concept - PF92 Bottom Bracket - 12 x 142mm Thru-axle | 02 Carbon - Tuned Compliance Concept - DTi
Fork:
02 Carbon | Tuned Compliance Concept | DTi
Cockpit
Handlebar:
BMC MFB 02 750mm
Stem:
BMC MSM 02
Seatpost:
BMC MSP 02
Saddle:
Fizik Antares R7
Seat
Seatpost:
BMC MSP 02
Saddle:
Fizik Antares R7
Drivetrain
Gears:
1 x 12
Crankset:
SRAM NX Eagle | 32T
Cassette:
SRAM NX Eagle | 11-50T
Chain:
SRAM NX Eagle
Rear Derailleur:
SRAM NX Eagle
Shifters:
SRAM NX Eagle
Brakes
Brake Levers / Calipers:
Shimano MT500 (160/160) *
Wheels
Rims:
Alex MD 25 **
Hubs (F/R):
Shimano Deore
Tires:
Vittoria Barzo G2,0 tubeless 2.25
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | 162-172 | 170-180 | 178-188 | >188 |
| Reach | 401 | 426 | 442 | 458 |
| Stack | 608 | 618 | 628 | 638 |
| Bar Drop | ||||
| Bar Reach | ||||
| Bar Rise | 4 | 4 | 4 | 4 |
| Bar Sweep | 9 | 9 | 9 | 9 |
| Bar Width | 720 | 720 | 720 | 720 |
| Base Bar Drop Flat Cockpit | ||||
| Base Bar Drop V-Cockpit | ||||
| Base Bar Reach Flat Cockpit | ||||
| Base Bar Reach V-Cockpit | ||||
| BB Drop | 61 | 61 | 61 | 61 |
| BB Drop (SLACK) | ||||
| BB Drop (STEEP) | ||||
| BB Height (SLACK) | ||||
| BB Height (STEEP) | ||||
| Chainstay | ||||
| Crank Length | 170 | 175 | 175 | 175 |
| LT | BB Drop (SLACK) | ||||
| LT | BB Drop (STEEP) | ||||
| LT | BB Height (SLACK) | ||||
| LT | BB Height (STEEP) | ||||
| LT | Chainstay | ||||
| LT | Fork Length | ||||
| LT | Fork Rake | ||||
| LT | Frame Size | ||||
| LT | Front Center (SLACK) | ||||
| LT | Front Center (STEEP) | ||||
| LT | Head Tube | ||||
| LT | HT Angle (SLACK) | ||||
| LT | HT Angle (STEEP) | ||||
| LT | Reach (SLACK) | ||||
| LT | Reach (STEEP) | ||||
| LT | Rider Height | ||||
| LT | Seat Tube | ||||
| LT | ST Angle @750mm Saddle Height (SLACK) | ||||
| LT | ST Angle @750mm Saddle Height (STEEP) | ||||
| LT | ST Angle Actual (SLACK) | ||||
| LT | ST Angle Actual (STEEP) | ||||
| LT | ST Angle Effective (SLACK) | ||||
| LT | ST Angle Effective (STEEP) | ||||
| LT | Stack (SLACK) | ||||
| LT | Stack (STEEP) | ||||
| LT | Stand Over Height (80 in Front of BB) | ||||
| LT | Stand Over Height (Lowest Point) | ||||
| LT | Top Tube (SLACK) | ||||
| LT | Top Tube (STEEP) | ||||
| LT | Wheelbase (SLACK) | ||||
| LT | Wheelbase (STEEP) | ||||
| ST | BB Drop (SLACK) | ||||
| ST | BB Drop (STEEP) | ||||
| ST | BB Height (STACK) | ||||
| ST | BB Height (STEEP) | ||||
| ST | Chainstay | ||||
| ST | Fork Length | ||||
| ST | Fork Rake | ||||
| ST | Frame Size | ||||
| ST | Front Center (SLACK) | ||||
| ST | Front Center (STEEP) | ||||
| ST | Head Tube | ||||
| ST | HT Angle (SLACK) | ||||
| ST | HT Angle (STEEP) | ||||
| ST | Reach (SLACK) | ||||
| ST | Reach (STEEP) | ||||
| ST | Rider Height | ||||
| ST | Seat Tube | ||||
| ST | ST Angle @750mm Saddle Height (SLACK) | ||||
| ST | ST Angle @750mm Saddle Height (STEEP) | ||||
| ST | ST Angle Actual (SLACK) | ||||
| ST | ST Angle Actual (STEEP) | ||||
| ST | ST Angle Effective (SLACK) | ||||
| ST | ST Angle Effective (STEEP) | ||||
| ST | Stack (SLACK) | ||||
| ST | Stack (STEEP) | ||||
| ST | Stand Over Height (80 in Front of BB) | ||||
| ST | Stand Over Height (Lowest Point) | ||||
| ST | Top Tube (SLACK) | ||||
| ST | Top Tube (STEEP) | ||||
| ST | Wheelbase (SLACK) | ||||
| ST | Wheelbase (STEEP) | ||||
| Fork Length | 506 | 506 | 506 | 506 |
| Fork Rake | 51 | 51 | 51 | 51 |
| Frame Size | ||||
| Front Center | 659 | 685 | 706 | 725 |
| Front Center (SLACK) | ||||
| Front Center (STEEP) | ||||
| Head Tube | 90 | 100 | 110 | 120 |
| Head Tube Angle | 70 | 70 | 70 | 70 |
| HT Angle (SLACK) | ||||
| HT Angle (STEEP) | ||||
| Pad Reach Flat Cockpit | ||||
| Pad Reach V-Cockpit | ||||
| Pad Stack Flat Cockpit | ||||
| Pad Stack V-Cockpit | ||||
| Reach (SLACK) | ||||
| Reach (STEEP) | ||||
| Rear Center | ||||
| Saddle Height Range | ||||
| Seat Angle | 73.5 | 73.5 | 73.5 | 73.5 |
| Seat Tube | 445 | 485 | 525 | 545 |
| Seatpost Drop | ||||
| Seatpost Length | 350 | 350 | 400 | 400 |
| Seatpost Offset | ||||
| ST Angle @750mm Saddle Height (SLACK) | ||||
| ST Angle @750mm Saddle Height (STEEP) | ||||
| ST Angle Actual (SLACK) | ||||
| ST Angle Actual (STEEP) | ||||
| ST Angle Effective (SLACK) | ||||
| ST Angle Effective (STEEP) | ||||
| Stack (SLACK) | ||||
| Stack (STEEP) | ||||
| Stand Over Height (80 in Front of BB) | ||||
| Stand Over Height (Lowest Point) | ||||
| Standover Height | ||||
| Stem Angle | ±6 | ±6 | ±6 | ±6 |
| Stem Length | 70 | 70 | 70 | 80 |
| Top Tube | 584 | 610 | 630 | 649 |
| Top Tube (SLACK) | ||||
| Top Tube (STEEP) | ||||
| Trail | 80 | 80 | 80 | 80 |
| Wheelbase | 1081 | 1107 | 1128 | 1146 |
| Wheelbase (SLACK) | ||||
| Wheelbase (STEEP) |
