Technical Overview
Frameset
Frame:
Teammachine SLR 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | TCC Race Compliance Level | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Teammachine SLR 01 Premium Carbon | ICS Technology Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Handlebar:
ICS Carbon | One-Piece Full Carbon Cockpit
Seat
Seatpost:
Teammachine SLR 01 Premium Carbon D-Shaped Seatpost
Saddle:
Fizik Argo Vento R3 | 140mm
Drivetrain
Crankset:
SHIMANO Ultegra (FC-R8100)
Chainrings:
52-36T
Cassette:
SHIMANO Ultegra (CS-R8100)
Cassette Size:
11-30T
Chain:
SHIMANO CN-M8100
Front Derailleur:
SHIMANO Ultegra Di2 (FD-R8150)
Rear Derailleur:
SHIMANO Ultegra Di2 (RD-R8150)
Shifters:
SHIMANO Ultegra Di2 (ST-R8170)
Gears:
2 x 12
Bottom Bracket:
PF86 Bottom Bracket
Brakes
Brake Levers / Calipers:
SHIMANO Ultegra (BR-R8170)
Rotors:
SHIMANO RT-MT800
Rotor Size (F/R):
160 / 140mm
Wheels
Rims:
DT Swiss ARC 1650 Carbon Disc | 50mm
Hubs (F/R):
DT Swiss ARC 1650 Disc
Tires:
Vittoria Corsa | 25mm
Tubeless Information:
Tubeless Ready Rims | Tubetype Tires
Accessories
In the Box:
Aerocore Bottle Cages
Additional Information
Tire Clearance:
30mm measured tire
Weight without Pedals:
7.60 kg | Size 54
ASTM Classification:
Level 1
System Weight Limit:
110kg
