Technical Overview
Frameset
Frame:
Teammachine SLR Carbon with Aerocore Design | Stealth Dropout Design | TCC Race Compliance Level | Flat Mount Disc | 12 x 142mm Thru-Axle | Optimized for Aerocore Bottle Cages
Fork:
Teammachine SLR Carbon | TCC Race Compliance Level | Internal Cable Routing | Flat Mount Disc | Stealth Dropout Design | 12 x 100mm Thru-Axle
Cockpit
Stem:
BMC RSM 01
Handlebar:
BMC RAB 03 | Ergo Top Shape | Compact Bend
Seat
Seatpost:
Teammachine SLR Carbon D-Shaped Seatpost
Saddle:
Fizik Antares R7
Drivetrain
Crankset:
SHIMANO 105 (FC-R7100)
Chainrings:
50-34T
Cassette:
SHIMANO 105 (CS-R7100)
Cassette Size:
11-34T
Chain:
SHIMANO CN-M6100
Front Derailleur:
SHIMANO 105 Di2 (FD-R7150)
Rear Derailleur:
SHIMANO 105 Di2 (RD-R7150)
Shifters:
SHIMANO 105 Di2 (ST-R7170)
Gears:
2 x 12
Bottom Bracket:
PF86 Bottom Bracket
Brakes
Brake Levers / Calipers:
SHIMANO 105 (BR-R7170)
Rotors:
SHIMANO SM-RT70
Rotor Size (F/R):
160 / 140mm
Wheels
Rims:
Mavic Open Disc
Hubs (F/R):
CL-712 (F) | RXC-1425 (R) | Thru-Axle
Tires:
Vittoria Rubino | 25mm
Tubeless Information:
Tubeless Ready Rims | Non-Tubeless Clincher Tire
Additional Information
Tire Clearance:
30mm measured tire
ASTM Classification:
Level 1
System Weight Limit:
110kg
