Technical Overview
Frameset
Frame:
Timemachine Road 01 Premium Carbon with Aero Module Tuned Compliance Concept Speed | ICS Aero Technology Stealth Cable Routing | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Timemachine Road 01 Premium Carbon with Integrated Aero Cover Tuned Compliance Concept Speed | ICS Technology Stealth Cable Routing | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Handlebar:
ICS Carbon Aero | One-Piece Full Carbon Cockpit | 135mm drop, 77mm reach, 12.5° flare
Seat
Seatpost:
Timemachine Road 01 Premium Carbon Aero Seatpost
Saddle:
Fizik Argo Vento R5 | 140mm
Drivetrain
Crankset:
SHIMANO Ultegra (FC-R8100)
Chainrings:
52-36T
Cassette:
SHIMANO Ultegra (CS-R8100)
Cassette Size:
11-30T
Chain:
SHIMANO CN-M8100
Front Derailleur:
SHIMANO Ultegra Di2 (FD-R8150)
Rear Derailleur:
SHIMANO Ultegra Di2 (RD-R8150)
Shifters:
SHIMANO Ultegra Di2 (ST-R8170)
Gears:
2 x 12
Bottom Bracket:
PF86 Bottom Bracket
Brakes
Brake Levers / Calipers:
SHIMANO Ultegra (BR-R8170)
Rotors:
SHIMANO RT-MT800
Rotor Size (F/R):
160 / 140mm
Wheels
Rims:
CRD-501 SL Carbon | Tubeless Ready | 50mm
Hubs (F/R):
CRD-501 SL
Tires:
Vittoria Corsa | 25mm
Accessories
In the Box:
Aerocore Bottle Cages
Additional Information
Tire Clearance:
28mm measured tire
ASTM Classification:
Level 1
System Weight Limit:
110kg
