Name: URS AL ONE
Brand: BMC
SKU: 30004984
Price: 2999.0 EUR
Availability: OutOfStock

URS AL ONE | BMC | bikes | Gravel, Gravel | Exploration

Metallic Grey Green / White

SRAM APEX
PRD23 Wheelset
Fender, Rack and Cargo Mounts

EUR 2.999,00

SKU: 30004984

Size —

Compatible Parts & Accessories

Shipped to your local bike shop

Check for availability within our Retailer Network

[{"id":40925501947983,"title":"XS","option1":"XS","option2":null,"option3":null,"sku":"30004983","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"URS AL ONE - XS","public_title":"XS","options":["XS"],"price":299900,"weight":15000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906506462","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40925502177359,"title":"S","option1":"S","option2":null,"option3":null,"sku":"30004984","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"URS AL ONE - S","public_title":"S","options":["S"],"price":299900,"weight":15000,"compare_at_price":null,"inventory_quantity":5,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906506554","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40925502210127,"title":"M","option1":"M","option2":null,"option3":null,"sku":"30004985","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"URS AL ONE - M","public_title":"M","options":["M"],"price":299900,"weight":15000,"compare_at_price":null,"inventory_quantity":18,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906506547","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40925502242895,"title":"L","option1":"L","option2":null,"option3":null,"sku":"30004986","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"URS AL ONE - L","public_title":"L","options":["L"],"price":299900,"weight":15000,"compare_at_price":null,"inventory_quantity":6,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906506530","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40925502275663,"title":"XL","option1":"XL","option2":null,"option3":null,"sku":"30004987","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"URS AL ONE - XL","public_title":"XL","options":["XL"],"price":299900,"weight":15000,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630906506523","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

URS AL ONE is the bicycle equivalent of a chameleon, able to adapt and perfectly fit in to diverse surroundings. Maintaining the URS family’s ride and handling characteristics, and offering even greater practicality, through additional cargo mounts and dropper post compatibility, it’s your bike for all reasons. The TCC Gravel Premium Aluminium frame and carbon fork are matched with the latest SRAM Apex 1x12 groupset, PRD23 wheelset and 45mm wide WTB tires.

Technical Overview

Frameset

Cockpit

Stem:
BMC MSM 02

Handlebar:
BMC RAB

Seat

Seatpost:
BMC RSP 03

Saddle:
Selle Royal

Drivetrain

Crankset:
SRAM Apex 1 DUB WIDE

Chainrings:
SRAM GX Eaglerings

Cassette:
SRAM Apex Eagle

Cassette Size:
11-50T

Chain:
SRAM GX Eagle

Rear Derailleur:
SRAM Apex Eagle

Shifters:
SRAM Apex

Gears:
1 x 12

Bottom Bracket:
PF86 Bottom Bracket

Brakes

Brake Levers / Calipers:
SRAM Apex

Rotors:
SRAM Centerline | Centerlock

Rotor Size (F/R):
160 / 160mm

Wheels

Rims:
PRD23 | 23mm

Hubs (F/R):
CL-712 (F) | RXC-1425 (R) | Thru-Axle

Tires:
WTB Riddler | 45mm

Additional Information

Tire Clearance:
45mm

ASTM Classification:
Level 2

System Weight Limit:
120kg

General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)

Size	XS	S	M	L	XL
Rider Height	< 165	162 - 172	170 - 182	180 - 192	>190
Reach	390	400	410	420	430
Stack	525	550	580	610	640
Bar Drop	130	130	130	130	130
Bar Reach	70	70	70	70	70
Bar Width	420	420	420	440	440
BB Drop	69	69	69	69	69
Crank Length	170	170	172.5	172.5	175
Fork Length	410	410	410	410	410
Fork Rake	45	45	45	45	45
Front Center	608	626	647	668	689
Head Tube	92	118	150	182	214
Head Tube Angle	70	70	70	70	70
Rear Center	430	430	430	430	430
Seat Angle	74	74	74	74	74
Seat Tube	430	445	475	505	540
Seatpost Length	350	350	350	350	350
Seatpost Offset	15	15	15	15	15
Standover Height	720	738	768	797	830
Stem Angle	±6	±6	±6	±6	±6
Stem Length	70	70	70	80	80
Top Tube	540	558	576	595	614
Trail	78	78	78	78	78
Wheelbase	1028	1047	1068	1089	1110
